The recommended parameters for 3000W laser cutting machine cutting 10mm carbon steel are: cutting speed 0.5-0.8 m/min, auxiliary gas usually uses oxygen or nitrogen, and the specific parameters need to be adjusted according to the equipment model and material characteristics.
Detailed explanation of cutting parameters
Cutting speed:
For 10mm carbon steel, the cutting speed of 3000W laser cutting machine is usually in the range of 0.5-0.8 m/min.
Too fast speed may lead to incomplete cutting, and too slow speed may increase the heat affected zone.
Assisted gas:
Oxygen: Commonly used for carbon steel cutting, it can increase cutting speed and improve incision quality.
Nitrogen: Suitable for high-precision cutting, can reduce oxide layer, but the cost is higher.
Focus position:
The focal position has a significant impact on cutting quality, and usually needs to be adjusted to the optimal position according to the material thickness.
Power setting:
3000W is enough to cut 10mm carbon steel, but the power output needs to be fine-tuned according to the actual cutting effect.
Precautions
Mass production recommendations: It is recommended to stabilize the speed at 0.8m/min for long-term operation to avoid frequent parameter adjustments that cause quality fluctuations.
Maintenance points: When cutting thick plates, the lens and gas nozzle need to be checked regularly to prevent slag clogging and affecting the beam quality.
