Laser cutting machine dust removal solutions mainly include the following methods:

1. Side suction dust removal system: Install a dust suction port on the side of the laser cutting machine to directly inhale the smoke generated during the cutting process. This method has a simple structure and low cost, and is suitable for small-scale operations.

2. Top dust suction system: The dust suction port is installed on the top of the laser cutting machine, which will not affect the cutting accuracy, but requires a higher installation space and is suitable for large-scale operations.

3. Central dust collection system: It is used for large-scale production lines to centrally process the smoke from multiple laser cutting machines. It has strong processing capacity, but requires a larger installation space and higher equipment investment.

4. Wet dust removal system: Use water or other liquids to absorb smoke, which has a good processing effect, but requires regular cleaning and replacement of liquids, and has a high operating cost.

5. Dry dust removal system: Such as the double-sided suction dust removal system, which collects smoke through a sliding suction duct, which is economical and easy to maintain.

‌Specific application examples of dust removal equipment‌ include:

‌1. Dust hood ‌: Installed on the laser cutting machine, collect dust through the pipe to ensure maximum dust capture‌.

‌2. Pulse bag dust collector ‌: Use bags to filter dust and remove accumulated dust through pulse blowing, with an efficiency of more than 99%‌.

‌3. Multi-stage filtration system ‌: Including primary, medium and high efficiency filtration, gradually remove dust particles‌.

‌Environmental protection and production safety measures‌ include:

‌1. Source control ‌: Optimize the cutting process to reduce dust generation‌.

2. Workshop ventilation and personal protection ‌: Strengthen ventilation to reduce dust concentration, and operators wear protective equipment such as dust masks‌
